Twin Line Tube and Pipe Clamp

Product Descriptions

Tube and Pipe Clamp is a product made from Polyproplene and Steel. It’s used to secure tube or pipe in place with its bolt and welded plate anchored to machinesry. And it offers a high degree of shock and vibration absoration and is widely applied in standard systems with less than 1500 PSI without dynamic loads.

Markets:

Automotive

Defence

Energy

Environment

Industrial

Infrastructure

Machine Tools

Materials Handling

Mobile

Oil and Gas

Power Generation

Process

Transportation

Water

Applications:

Suitable for general hydraulic applications

Features/Benefits:

The function of tube clamp is the fixing of straight tubes, bent tubes, and hoses.

Its noteable features are re-set capability, high tensile strength, very high abrasion resistance and excellent resistance to cold.

Specifications:

Material: Polypropylene and Steel

Polyamide&Steel, Aluminum are both available.

Complied with DIN 3015

Standard Duty Tube Clamp for normal mechanical requirements are available in

8 sizes. Outer tube diameter for the metric series 6-102mm.

Heavy Duty Tube Clamp for high mechanical requirements are available in 11

sizes. Outer tube diameter for the metric series 6-508mm.

Twin Tube Clamp for normal mechanical requirements are available in 5 sizes.

Outer tube diameter for the metric series 6-42.

Polypropylene -30°C-90°C, color dark green

Polyamide -40°C-120°C, color black

Aluminum +300°C

All metal parts are also available in stainless steel. Other materials upon request.

Clamp Size	Outer Diameter	Inner Diameter	Outer Diameter	Item Number
	mm	inch	inch	2 clamp halves weld plate, hex head bolt
1	6			TPCTTPG1-106
	6.4			TPCTTPG1-106.4
	8		1/4	TPCTTPG1-108
	9.5		5/16	TPCTTPG1-109.5
	10	G1/8	3/8	TPCTTPG1-110
	12			TPCTTPG1-112
2	12.7		1/2	TPCTTPG1-212.7
	13.5			TPCTTPG1-213.5
	14	G1/4		TPCTTPG1-214
	15			TPCTTPG1-215
	16		5/8	TPCTTPG1-216
	17.2	G3/8		TPCTTPG1-217.2
	18			TPCTTPG1-218
3	19		3/4	TPCTTPG1-319
	20			TPCTTPG1-320
	21.3			TPCTTPG1-321.3
	22	G1/2		TPCTTPG1-322
	23			TPCTTPG1-323
	25			TPCTTPG1-325
	25.4		1	TPCTTPG1-325.4
4	26.9	G3/4		TPCTTPG1-426.9
	28			TPCTTPG1-428
	30			TPCTTPG1-430
5	32	G1		TPCTTPG1-532
	33.7			TPCTTPG1-533.7
	35		1 1/4	TPCTTPG1-535
	38			TPCTTPG1-538
	40	G1 1/4	1 1/2	TPCTTPG1-540
	42			TPCTTPG1-542
